Product Name : FRD 24


Product Code : 5098514


Product Group : OBO Products / Surge arrestor(class B+C+D)



parameter unit amount
Maximum continuous voltage AC UC 19
Maximum continuous voltage DC UC 28
Category   Type 1+2+3 / D1+C2+C1
Lightning protection zone LPZ   0→3
Number of poles   2
Rated current IL 0,2
Series resistance per wire   15 Ω ± 10 %
Impulse durability wire-wire   C2: 5 kV / 2,5 kA (8/20µs)
Impulse durability wire-earth   C2: 10 kV / 5 kA (8/20µs)
Total discharge current (8/20)   10
Total discharge current (10/350)   D1: 3
Protection level wire-wire   <60
Protection level wire-earth   <600
Temperature range ϑ -40-80
Installation type   Hat rail 35 mm
Connection system   Terminal
Division unit TE (17.5 mm)   1
Protection rating   IP20
Connection cross-section, flexible   0,14-2,5
Connection cross-section, multi-wire   0,14-2,5
Connection cross-section rigid   0,14-2,5
Earthing via:   Terminal
Testing standard   IEC 61643-21
