Product Name : KOAX B-E2 FF-F


Product Code : 5082434


Product Group : OBO Products / Surge Arrestor (class C+D)



parameter unit amount
Maximum continuous voltage AC UC 4,2
Maximum continuous voltage DC UC 6,2
Category   Type 2+3 / C2+C1
Lightning protection zone LPZ   1→3
Number of poles   1
Rated current IL 1
Series resistance per wire   —
Wave resistance ZL 75
Impulse durability wire-wire   C1: 1 kV / 0,5 kA (8/20µs)
Impulse durability wire-earth   C2: 10 kV / 5 kA (8/20µs)
Impulse discharge current (10/350) Iimp —
Total discharge current (8/20)   10
Total discharge current (10/350)   —
Protection level wire-wire   <40
Protection level wire-earth   <600
Frequency range   0 - 160 MHz
Insertion loss S21 ≤1,7
Return loss S11 ≥14
Temperature range ϑ -20-80
Installation type   Connector/cable adapter
Connection system   BNC
Protection rating   IP40
Shielding connection available   Yes
Shield connection   Direct
Earthing via:   —
Testing standard   IEC 61643-21
