Product Name : KOAX B-E2 MF-C


Product Code : 5082430


Product Group : OBO Products / Surge arrestor(class B+C+D)





parameter unit amount
Maximum continuous voltage AC UC 4,2
Maximum continuous voltage DC UC 6,2
Category   Type 1+2+3 / D1+C2+C1
Lightning protection zone LPZ   0→3
Number of poles   1
Rated current IL 0,3
Series resistance per wire   4,7 Ω ± 10%
Wave resistance ZL 75
Impulse durability wire-wire   C2: 10 kV / 5 kA (8/20µs)
Impulse durability wire-earth   C2: 10 kV / 5 kA (8/20µs)
Impulse discharge current (10/350) Iimp 1
Total discharge current (8/20)   10
Total discharge current (10/350)   2
Protection level wire-wire   <75
Protection level wire-earth   <600
Frequency range   0 - 68 MHz
Insertion loss S21 ≤1,7
Return loss S11 ≥14
Temperature range ϑ -20-80
Installation type   Connector/cable adapter
Connection system   BNC
Protection rating   IP40
Shielding connection available   Yes
