Product Name : DS-7 16 M/W


Product Code : 5093171


Product Group : OBO Products / Surge Arrestor (class B+c)



parameter unit amount
Maximum continuous voltage AC UC 130
Maximum continuous voltage DC UC 185
Category   Type 1+2 / D1+C2
Lightning protection zone LPZ   0→2
Number of poles   1
Rated current IL 10
Wave resistance ZL 50
Impulse durability wire-wire   C2: 10 kV / 5 kA (8/20µs)
Impulse durability wire-earth   C2: 10 kV / 5 kA (8/20µs)
Impulse discharge current (10/350) Iimp 2,5
Total discharge current (8/20)   10
Total discharge current (10/350)   5
Protection level   <800
Frequency range   0 - 3 GHz
Insertion loss S21 ≤0,95
Return loss S11 ≥14
Temperature range ϑ -40-80
Installation type   Connector/cable adapter
Connection system   42932
Protection rating   IP40
Shielding connection available   Yes
Shield connection   Direct
Testing standard   IEC 61643-21
