Product Name : MDP-4 D-24-T


Product Code : 5098431


Product Group : OBO Products / Surge arrestor(class B+C+D)



parameter unit amount
Maximum continuous voltage AC UC 20
Maximum continuous voltage DC UC 28
Category   Type 1+2+3 / D1+C2+C1
Lightning protection zone LPZ   0→3
Number of poles   4
Rated current IL 0,58
Series resistance per wire   2,35 Ω ± 5 %
Impulse durability wire-wire   C1: 0,5 kV / 0,25 kA (8/20µs)
Impulse durability wire-earth   C2: 5 kV / 2,5 kA (8/20µs)
Total discharge current (8/20)   10
Total discharge current (10/350)   D1: 2
Protection level wire-wire   <55
Protection level wire-earth   <800
Frequency range   0 - 100 MHz
Temperature range ϑ -40-80
Installation type   Hat rail 35 mm
Connection system   Terminal
Protection rating   IP20
Shielding connection available   Yes
Shield connection   Direct
Connection cross-section, flexible   0,14-2,5
Connection cross-section, multi-wire   0,14-1,5
Connection cross-section rigid   0,14-2,5
Earthing via:   DIN rail
Testing standard   IEC 61643-21
