Product Name : V50-3+NPE+FS-280


Product Code : 5093533


Product Group : OBO Products / Surge Arrestor (class B+c)





parameter unit amount
SPD to EN 61643-11   Type 1+2
SPD to IEC 61643-11   Class I+II
SPD to UL 1449   Type 4
Nominal voltage AC (50 / 60 Hz) Un 230
Maximum continuous voltage AC UC 280
Nominal discharge current (8/20 µs) In / L-N 30
Maximum discharge current (8/20 μs) Imax 50
Lightning surge current (10/350 μs) Iimp 12,5
Total discharge current (10/350) Itotal 50
Arrestor surge current (8/20 µs) [total] Itotal 80
Protection level [L-N] Up 1,3
Residual voltage [L-N] @ 1 kA Ures 1
Residual voltage [L-N] @ 5 kA Ures 1
Max. mains-side overcurrent protection   160 A gL/gG
Short-circuit withstand for max. mains-side overcurrent protection   50 kA eff
Operating temperature range Tu -40-80
Protection rating   IP20
Approvals   ÖVE
FM contacts   Changeover
Switching power AC   230 V; 0,5 A
Switching power DC   230 V; 0,1 A / 75 V; 0,5 A
Connection cross-section, FM terminals   0-2
Connection cross-section, FM terminals   21-16
Cable cross-section, flexible (fine-wire)   1,5-35
Rigid cable cross-section (single wire/multiwire)   1,5-35
Cable cross-section, flexible (fine-wire)   16-2
Rigid cable cross-section (single wire/multiwire)   16-2
