Product Name : V25-B+C 1+NPE+FS


Product Code : 5094444


Product Group : OBO Products / Surge Arrestor (class B+c)







parameter unit amount
Nominal voltage UN 230
SPD to EN 61643-11   Type 1+2
SPD to IEC 61643-11   Class I+II
Lightning protection zone LPZ   0→2
Impulse discharge current (10/350) Iimp 7
Total discharge current (10/350) Itotal 14
Nominal discharge current (8/20) In 30
Arrestor surge current (8/20 µs) [total] ITotal 8/20 60
Maximum discharge current (8/20 μs) Imax 50
Voltage protection level Up <0.9
Response time tA <25
Maximum back-up fuse   160
Temperature range ϑ -40-80
Division unit TE (17.5 mm)   2
Protection rating   IP20
Connection cross-section rigid   2,5-35
Connection cross-section, multi-wire   2,5-35
Connection cross-section, flexible   2,5-25
